Разширителен слот:
1x PCIe x8 LP, 1x PCIe x16 LP
Захранване:
1x 750W Platinum
Дисков контролер:
RAID 0/1/10/5/50 with RAID 530-8i
Брой поддържани дискове:
8x 2.5" SATA/SAS HS
Порт за отдалечено управление:
1x dedicated 1GbE management port (std)
Памет, GB:
16GB (1x16GB, 2Rx8 RDIMM)
Памет, слотове:
Up to 12 DIMM sockets (6 DIMMs per processor 6 memory channels per processor with one DIMM per channel) with support for the following TruDDR4 RDIMM types and capacities: 8 GB, 16 GB, 32 GB, and 64 GB 2933 MHz 16 GB and 32 GB 2666 MHz Up to 768 GB
Съвместими операционни системи:
Microsoft Windows Server 2016 and 2019 Red Hat Enterprise Linux 7 SUSE Linux Enterprise Server 12 and 15 VMware vSphere (ESXi) 6.5 and 6.7
Софтуер за управление:
XClarity Advanced
Процесор:
Intel Xeon Silver 4210 (10C, 2.2GHz, 13.75MB Cache, 85W)
Интерфейс:
Front: 1x USB 2.0 port with XClarity Controller access and 1x USB 3.0 port optional 1x VGA port Rear: 2x USB 3.0 ports and 1x VGA port optional 1x DB-9 serial port
Серия:
Think System SR530
Мрежа:
2x 1GbE ports + 1x dedicated 1GbE management port (std) optional modular LOM supports 2x 1GbE Base-T or 2x 10GbE with Base-T or SFP+
