Х-ка 1:
Video compression: H.265 Pro+ Audio compression: G.711u
Power Over Ethernet (PoE):
-
Брой канали:
8-ch, BNC interface (1.0 Vp-p, 75 Ohm), supporting coaxitron connection
Х-ка 8:
Dimensions (WxDxH): 260 x 222 x 45 mm Working temperature: -10 °C to + 55 °C Working humidity: 10% to 90% Power supply: 12 VDC, 12 W max.
Х-ка 5:
Network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS Remote connections 128
Х-ка 3:
Audio output: 1-ch, RCA (Linear, 1 KOhm) Dual stream - Support
Х-ка 7:
Auxiliary interface: 1 SATA interface (Up to 10 TB capacity for each disk) USB interface: Rear panel: 2 x USB 2.0
Х-ка 4:
Other inputs: Turbo HD input AHD input HDCVI input CVBS input Audio input (1-ch, RCA) IP video input - 4-ch (up to 12-ch), Up to 6 MP resolution
Х-ка 6:
Network interface: 1, RJ45 10M/100M self-adaptive Ethernet interface
Х-ка 2:
HDMI/VGA output: 1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
