Name: Комутатор HPE OfficeConnect 1950 24G 2SFP+ 2XGT PoE+ Switch
Brand: HPE
SKU: HPE-JG962A
Price: 1875.80000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

Размери (Ш, Д, В), mm:

440 x 360 x 44

Основни портове, тип:

24x10/100/1000Base-T

Памет (Flash, RAM):

Flash Memory: 128 MB RAM: 1 GB SDRAM

MAC адреси:

16384 MAC addres table size

Опция за монтаж:

Desktop/Rackmount

Свободни (10GB) слотове:

Общ брой портове:

Пропускателна способност, Mpps:

95.2 Mpps

Uplink портове:

2x10GE SFP, 2x10GBase-T

Гаранция:

99 месеца

Суич, тип:

Fixed Port

Fans:

Low-speed fan: 37.3 dB, High-speed fan: 47.1 dB

Stackable:

True stacking allows for redundancy while simplifying administration

Routing:

Layer 3 Lite

Капацитет за маршрутизиране/превключване, Gbps:

128 Gbps

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3i, IEEE 802.3x, IEEE 802.3z, IEEE 802.3az, IEEE 802.1s, IEEE 802.1w, IEEE 802.1D MAC Bridges, IEEE 802.1D STP, IEEE 802.1p, IEEE 80

Сигурност:

Access Control Lists (ACLs) IEEE 802.1X and RADIUS network logins Port isolation ARP attack protection Automatic VLAN assignment STP BPDU port protection STP root guard Automatic denial-of-service protection Management password

IPv6 functionality:

IPv6 host, IPv6 routing, MLD snooping, IPv6 ACL/QoS

QoS:

Broadcast control, Rate limiting, Traffic prioritization (Recognizes both IEEE 802.1p and DSCP prioritization tagging. Packets are mapped to four hardware queues for more effective throughput), Powerful QoS feature (SP, WRR and SP+WRR queuing)

Power Over Ethernet (PoE):

IEEE 802.3af and IEEE 802.3at PoE power: 370 W PoE+

VLAN (брой, стандарти):

Supports IEEE 802.1Q with 4, 094 simultaneous VLAN IDs

Захранване:

AC voltage: 100-240 VAC Maximum power rating: 425 W Available redundant power supply - Provides additional PoE of up to 740 W. HP RPS1600 Redundant Power System (JG136A) is sold separately. Max. power consumption with RPS is 770 W.

Други:

1 RJ-45 console port to access limited CLI port

L3 мрежови стандарти:

Static IPv4/IPv6 routing: provides basic routing (supporting up to 512 static routes and 32 VLAN interface on aggregation model 32 static routes and 8 VLAN interfaces on access models) allows manual routing configuration

Управление:

Intuitive Web browser-based management Secure Web-management sessions with HTTPS/SSL SNMPv1, v2c, and v3 Complete session logging Dual flash images Port mirroring RMON NTP IEEE 802.1AB Link Layer Discovery Protocol (LLDP) CLI Default DHCP c

Описание

Комутатор HPE OfficeConnect 1950 24G 2SFP+ 2XGT Po
