Основни портове, тип:
8x10/100/1000Base-T
Размери (Ш, Д, В), mm:
254 x 160 x 44
VLAN (брой, стандарти):
VLAN support and tagging - supports up to 64 port-based VLANs and dynamic configuration of IEEE 802.1Q VLAN tagging, providing security between workgroups Jumbo packet support
Power Over Ethernet (PoE):
No
Пропускателна способност, Mpps:
11.9 Mpps
Памет (Flash, RAM):
Flash Memory: 16 MB, RAM: 128 MB SDRAM
MAC адреси:
8000 MAC address table size
Сигурност:
Secure Sockets Layer (SSL): encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch Automatic denial-of-service protection: monitors 9 types of malicious attacks and protects the network by blocking the at
Управление:
Simple Web management: intuitive Web GUI allows for easy management of device by even nontechnical users SNMPv1, v2c Dual flash images Port mirroring Network Time Protocol (NTP) Manual network time configuration Default DHCP client mode
Капацитет за маршрутизиране/превключване, Gbps:
16 Gbps
L2 мрежови стандарти:
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x
Свободни (10GB) слотове:
No
QoS:
IEEE 802.1p/Q, Broadcast control - Allows limiting of broadcast traffic rate to reduce unwanted network broadcast traffic, Traffic prioritization
Опция за монтаж:
Desktop/Rackmount
