Захранване:
Integrated power supply: 40W AC Optional external power supply RPS720 (sold separately)
Управление:
Management via an intuitive and familiar CLI, embedded web server (GUI), SNMP-based management console application (including Dell OpenManage Network Manager), Telnet or serial connection.
MAC адреси:
16000 MAC address table size
Uplink портове:
4x10GE SFP
Свободни (10GB) слотове:
No
Размери (Ш, Д, В), mm:
440 x 257 x 43
L2 мрежови стандарти:
IEEE 802.1AB, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1S, IEEE 802.1v, IEEE 802.1W, IEEE 802.1X, IEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3AX, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Power Over Ethernet (PoE):
No
Основни портове, тип:
24x10/100/1000Base-T
Пропускателна способност, Mpps:
128 Mpps
Опция за монтаж:
Rackmount
Други:
RJ45 console port with RS232 signaling (RJ-45 to female DB-9 connector cable included), USB (Type A) port for configuration via USB flash drive
QoS:
8 priority queues per port, DiffServ, Flow Based QoS, Port Based QoS
Fans:
Redundant variable speed fans
L3 мрежови стандарти:
Static routing and Routing Information ProtocoL (RIPv1, RIPv2) 128 RIP routing interfaces
Капацитет за маршрутизиране/превключване, Gbps:
128 Gbps
IPv6 functionality:
General IPv6 protocols are supported
Памет (Flash, RAM):
Flash Memory: 256 MB, RAM: 1 GB
Сигурност:
AAA authorization, TACACS+ accounting and RADIUS support for comprehensive secure access support
VLAN (брой, стандарти):
802.1Q VLAN Tagging, Double VLAN Tagging, GVRP Private VLAN extensions and Private VLAN Edge support 128 VLAN routing interfaces 512 VLANs supported Protocol-based VLANs Max VLAN interfaces with ACLs applied: 24
