Комутатор D-Link xStack 20-port SFP Layer 3 Stacka

Name: Комутатор D-Link xStack 20-port SFP Layer 3 Stacka
Brand: D-LINK
SKU: D-LINK-DGS-3630-28SC-SI
Price: 1762.30000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Каталожен № на продукта: D-LINK-DGS-3630-28SC-SI

komutator-d-link-xstack-20-port-sfp-layer-3-stacka-d-link-dgs-3630-28sc-si

0 ревюта | 0 въпроса

Управление Web-based GUI, Command Line Interface (CLI), Telnet Server, Telnet Client, SNMP v1/v2c/v3, SNMP Trap, TFTP, FTP, RCP, SMTP, RMONv1 (Supports 1,2,3,9 groups), RMONv2 (Supports ProbeConfig group), D-Link Discover Protocol (DDP), sFlow, Debug Command
Stackable Physical Stacking: Up to 80 Gbps stacking bandwidth, Up to 9 switches in a stack, Ring/chain topology support Virtual Stacking/Clustering of up to 32 units: Supports D-Link Single IP Management, Up to 20 Gbps stacking bandwidth
Сигурност Port Security, Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, Dynamic ARP Inspection, IP Source Guard, DHCP Snooping, IPv6 Snooping, Dynamic ARP Inspection (DAI), SSL, SSH, BPDU Attack Prevention
Опция за монтаж Rackmount
L2 мрежови стандарти IEEE 802.3, IEEE 802.3u, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X, IEEE 802.1Q, IEEE 802.1Qbb, IEEE 802.1p, IEEE 802.1v, IEEE 802.1AX

Сравни

1762.30 €

3446.76 лв.

Неналичен. Цената може да бъде различна, когато отново има наличност.

Добави в Любими

Поръчка по телефон Без формалности

Комутатор D-Link xStack 20-port SFP Layer 3 Stacka

1762.30 € 3446.76 лв.

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

Управление:

Web-based GUI, Command Line Interface (CLI), Telnet Server, Telnet Client, SNMP v1/v2c/v3, SNMP Trap, TFTP, FTP, RCP, SMTP, RMONv1 (Supports 1, 2, 3, 9 groups), RMONv2 (Supports ProbeConfig group), D-Link Discover Protocol (DDP), sFlow, Debug Command

Stackable:

Physical Stacking: Up to 80 Gbps stacking bandwidth, Up to 9 switches in a stack, Ring/chain topology support Virtual Stacking/Clustering of up to 32 units: Supports D-Link Single IP Management, Up to 20 Gbps stacking bandwidth

Сигурност:

Port Security, Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, DHCP Server Screening, Dynamic ARP Inspection, IP Source Guard, DHCP Snooping, IPv6 Snooping, Dynamic ARP Inspection (DAI), SSL, SSH, BPDU Attack Prevention

Опция за монтаж:

Rackmount

Общ брой портове:

MAC адреси:

68000 MAC address table size

IPv6 functionality:

IPv6 Tunnelling: Static, ISATAP, GRE, 6to4 IPv6 Traffic Class IPv6 Flow Label

Суич, тип:

Fixed Port

Пропускателна способност, Mpps:

95.24 Mpps

Гаранция:

99 месеца

Размери (Ш, Д, В), mm:

440 x 260 x 44

Power Over Ethernet (PoE):

Uplink портове:

4 dual personality, 4x10GE SFP

Routing:

Layer 3 RIP

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X, IEEE 802.1Q, IEEE 802.1Qbb, IEEE 802.1p, IEEE 802.1v, IEEE 802.1AX

Свободни (10GB) слотове:

Fans:

2 x smart fans (By default, the fan speed is low. When the temperature inside the chassis is over 36 °C, the fans switch to high speed until the temperature drops below 33 °C)

Памет (Flash, RAM):

L3 мрежови стандарти:

Static Route: Max. 512 IPv4 entries, Max. 256 IPv6 entries IPv4/IPv6 Default Route BFD (Bidirectional Forwarding Detection) - IPv4/v6 Static Route, RIP, VRRP RIPv1/v2/ng

QoS:

802.1p, 8 queues per port, Queue Handling (Strict Priority (SP), Weighted Round Robin (WRR), Strict + WRR, Weighted Deficit Round Robin (WDRR)), Congestion Control, 802.1Qbb Priority-based Flow Control (PFC) for 10 GbE port, Bandwidth Control, Policy

Основни портове, тип:

20xSFP

Капацитет за маршрутизиране/превключване, Gbps:

128 Gbps

Захранване:

Optional Redundant Power Supply: DPS-500A

Други:

RJ45 and Mini USB console ports for out-of-band CLI management, 10/100/1000BASE-T RJ-45 Ethernet for out-of-band IP management, 1 RJ-45 port Alarm port, 1 USB 2.0 Type A port, Stacking cable and USB flash card not included

VLAN (брой, стандарти):

VLAN Group: Max. 4K VLAN groups, Max. 4094 VIDs Multicast VLAN (ISM VLAN for IPv4/IPv6) Voice VLAN Auto Surveillance VLAN VLAN Trunking GVRP: Up to 4K dynamic VLANs Asymmetric VLAN 802.1Q 802.1v Protocol-based VLAN Double VLAN Private VLAN

Описание

Комутатор D-Link xStack 20-port SFP Layer 3 Stacka
