Комутатор D-Link 24 Ports SFP Plus 4 Port 10G SFP+ ... with Single AC input Виж още

Name: Комутатор D-Link 24 Ports SFP Plus 4 Port 10G SFP+ with Single AC input
Brand: D-LINK
SKU: D-LINK-DIS-700G-28XS
Price: 8298.00000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Каталожен № на продукта: D-LINK-DIS-700G-28XS

komutator-d-link-24-ports-sfp-plus-4-port-10g-sfp-d-link-dis-700g-28xs

0 ревюта | 0 въпроса

MAC адреси 8000 MAC address table size
QoS 8 queues per port Scheduling Schemes - SPQ, WRR, SPQ + WRR Ingress rate limit in 1K bps granularity TrTCM (Two Rate Three Color Marker) policer engine Traffic Shaper - Hierarchical per port and per queue shaping & scheduling with bandwidth man
Routing Layer 2 Only
VLAN (брой, стандарти) IEEE 802.1Q tag-based VLANs, Port-based VLANs, IEEE 802.1v protocol-based VLANs, IEEE 802.1ad Double Tagging (Q in Q), Private VLAN, 2048 Max VLANs, MVR (Multicast VLAN Registration), Attach/Remove/Replacement VLAN tag Operations
Основни портове, тип 24xSFP

Сравни

8298.00 лв

Неналичен. Цената може да бъде различна, когато отново има наличност.

Добави в Любими

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

Power Over Ethernet (PoE):

Захранване:

AC Inputs: 100/240 VAC, 50Hz ~ 60Hz Power Consumption: 35W

Основни портове, тип:

24xSFP

IPv6 functionality:

Памет (Flash, RAM):

L3 мрежови стандарти:

Размери (Ш, Д, В), mm:

440 x 319 x 44

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1X, IEEE 802.1ad

Свободни (10GB) слотове:

Fans:

Fanless design

Uplink портове:

4x10GE SFP

Управление:

Industrial-like CLI (command line interface) WEB-based Management SNMP v1, v2c, v3 Telnet (5 sessions) TFTP/FTP for Configuration Import/Export and Firmware Upgrade HTTPs, SSH Management Security NTP/SNTP Syslog, Policy-based stream mirroring

Суич, тип:

Fixed Port

MAC адреси:

8000 MAC address table size

QoS:

8 queues per port Scheduling Schemes - SPQ, WRR, SPQ + WRR Ingress rate limit in 1K bps granularity TrTCM (Two Rate Three Color Marker) policer engine Traffic Shaper - Hierarchical per port and per queue shaping &amp scheduling with bandwidth man

Опция за монтаж:

Rackmount

Общ брой портове:

VLAN (брой, стандарти):

IEEE 802.1Q tag-based VLANs, Port-based VLANs, IEEE 802.1v protocol-based VLANs, IEEE 802.1ad Double Tagging (Q in Q), Private VLAN, 2048 Max VLANs, MVR (Multicast VLAN Registration), Attach/Remove/Replacement VLAN tag Operations

Stackable:

Сигурност:

Port Security - IP and MAC-based Access control, Policy-based Access control, IEEE 802.1X authentication, Network Access Control, RADIUS Client for IEEE 802.1X Storm Control - Multicast/Broadcast/Flooding Storm Control on per port and per VLAN basis

Routing:

Layer 2 Only

Гаранция:

60 месеца

Описание

Комутатор D-Link 24 Ports SFP Plus 4 Port 10G SFP+
