Power Over Ethernet (PoE):
No
Захранване:
Internal power supply: 100 to 240 VAC
Основни портове, тип:
14x10GE SFP
IPv6 functionality:
IPv6 Neighbor Discovery (ND)
Памет (Flash, RAM):
Flash: 128 MB
Размери (Ш, Д, В), mm:
440 x 250 x 44
L2 мрежови стандарти:
IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3an, IEEE 802.3ae, IEEE 802.3z, IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1D, IEEE 802.1w, IEEE 802.1AX, IEEE 802.3ad
Свободни (10GB) слотове:
No
Uplink портове:
2 dual personality
Управление:
Web-based GUI, D-Link Network Assistant Utility, TFTP client, SNMP (Support v1/v2c/v3), SNMP trap, LLDP, LLDP-MED, System Log, SNTP, ICMPv6, Dual Images, Dual Configurations, RMON v1/v2
MAC адреси:
16000 MAC address table size
Капацитет за маршрутизиране/превключване, Gbps:
320 Gbps
QoS:
802.1p Priority Queue 8 queues per port Queue Handling: Strict Priority Queue, Weighted Round Robin (WRR) Bandwidth Control - Port-based (Ingress/Egress, min. granularity 64 Kbps) CoS based on 802.1p Priority
Опция за монтаж:
Rackmount
VLAN (брой, стандарти):
802.1Q VLAN, Port-based VLAN, 128 VLAN Groups, Configurable VID 1-4094, Voice VLAN, Auto Surveillance VLAN, Asymmetric VLAN
Сигурност:
Broadcast/Multicast/Unicast Storm Control, D-Link Safeguard Engine, Traffic Segmentation, SSL (Support v1/v2/v3, Support IPv4/IPv6), ARP Spoofing Prevention (Max. 128 entries), DoS Attack Prevention (Port Security), Duplicate Address Detection (DAD)
Пропускателна способност, Mpps:
238.096 Mpps
