Основни портове, тип:
12x 10BASE-T/100BASE-TX/1000BASE-T/10GBASE-T, RJ-45, 12x 10GE SFP+ slots, 1x GE OOB port, 1x console, RJ45, 1x RPS port
Размери (Ш, Д, В), mm:
440 x 350 x 44
Капацитет за маршрутизиране/превключване, Gbps:
480 Gbps
MAC адреси:
32 000 MAC address table size
Захранване:
100 - 240V 47 - 63 Hz, internal, universal
Памет (Flash, RAM):
Flash Memory: 256 MB RAM: 512 MB
Свободни (10GB) слотове:
No
IPv6 functionality:
IPv6 host mode IPv6 over Ethernet Dual IPv6/IPv4 stack IPv6 neighbor and router discovery (ND) IPv6 Stateless Address Autoconfiguration Path MTU Discovery IPv6 over IPv4 network with ISATAP tunnel support USGv6 and IPv6 Gold Logo certified
Опция за монтаж:
Rack-mountable, 1RU
Power Over Ethernet (PoE):
No
L3 мрежови стандарти:
IPv4 routing: Wirespeed routing of IPv4 packets, Up to 7K routes and up to 256 IP interfaces Wirespeed IPv6 static routing: Up to 7K routes and up to 256 IPv6 interfaces Routing Information Protocol version 2 for dynamic routing VRRP versions 2 an
Пропускателна способност, Mpps:
240 Mpps
Управление:
1x GE OOB management port (Dedicated Gigabit management port for out-of-band management)
Uplink портове:
12x 10 GE SFP+
Stackable:
Hardware stack: Up to 8 units in a stack. Up to 400 ports managed as a single system with hardware failover.
Routing:
Layer 3 RIP (RIPv2, VRRP, PBR, static IPv4/IPv6 routing)
QoS:
Priority levels: 8 hardware queues Scheduling: Strict priority and weighted round-robin (WRR) Class of service Rate limiting Congestion avoidance
VLAN (брой, стандарти):
Support for up to 4094 active VLANs simultaneously Port-based and 802.1Q tag-based VLANs MAC-based VLAN Management VLAN Private VLAN Guest VLAN Dynamic VLAN
L2 мрежови стандарти:
802.3, 802.3u, 802.3z, 802.1D, 802.1Q, 802.3ab, 802.3ae, 802.3an, 802.1p, 802.3x, 802.3ad (LACP), 802.1w, 802.1x, 802.1s, 802.3az
Сигурност:
SSH SSL IEEE 802.1X (authenticator role) Web-based authentication STP BPDU/Root Guard DHCP snooping Dynamic ARP Inspection (DAI) IP/MAC/Port Binding (IPMB) Secure Core Technology (SCT) Secure Sensitive Data (SSD) DoS prevention RADIUS/TACA
