Name: Комутатор Cisco SF550X-24P 24-port 10/100 PoE Stackable Switch
Brand: CISCO
SKU: CISCO-SF550X-24P-K9-EU
Price: 1360.86999999999989086064 BGN
Availability: InStock
Rating: 0 (0 reviews)

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

Захранване:

Internal power supply: 100-240V, 47-63 Hz Cisco external redundant power supply (RPS2300)

Сигурност:

SSH SSL IEEE 802.1X (authenticator role) Web-based authentication STP BPDU/Root Guard DHCP snooping Dynamic ARP Inspection (DAI) IP/MAC/Port Binding (IPMB) Secure Core Technology (SCT) Secure Sensitive Data (SSD) DoS prevention RADIUS/TACA

Опция за монтаж:

Rack-mountable, 1RU

Uplink портове:

2 dual personality, 2x10GE SFP

Stackable:

Hardware stack: Up to 8 units in a stack. Up to 400 ports managed as a single system with hardware failover.

Routing:

Layer 3 RIP

Капацитет за маршрутизиране/превключване, Gbps:

84.8 Gbps

Power Over Ethernet (PoE):

Support 802.3at PoE+, 802.3af PoE, and Cisco prestandard (legacy) PoE. Number of Ports That Support PoE: 24 (8 support 60W PoE). Power Dedicated to PoE: 195W

Суич, тип:

Fixed Port

Пропускателна способност, Mpps:

63.09 Mpps

Основни портове, тип:

24x10/100Base-TX

Свободни (10GB) слотове:

Fans:

2 + 1 (redundant) fans

IPv6 functionality:

IPv6 host mode IPv6 over Ethernet Dual IPv6/IPv4 stack IPv6 neighbor and router discovery (ND) IPv6 Stateless Address Autoconfiguration Path MTU Discovery IPv6 over IPv4 network with ISATAP tunnel support USGv6 and IPv6 Gold Logo certified

VLAN (брой, стандарти):

Support for up to 4094 active VLANs simultaneously Port-based and 802.1Q tag-based VLANs MAC-based VLAN Management VLAN Private VLAN Guest VLAN Dynamic VLAN

L3 мрежови стандарти:

IPv4 routing: Wirespeed routing of IPv4 packets, Up to 7K routes and up to 256 IP interfaces Wirespeed IPv6 static routing: Up to 7K routes and up to 256 IPv6 interfaces Routing Information Protocol version 2 for dynamic routing VRRP versions 2 an

Общ брой портове:

Управление:

Web user interface: Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS) SNMP: SNMP versions 1, 2c, and 3 with support for traps, and SNMP version 3 user-based security model (USM)

Памет (Flash, RAM):

Flash Memory: 256 MB RAM: 512 MB

QoS:

Priority levels: 8 hardware queues Scheduling: Strict priority and weighted round-robin (WRR) Class of service Rate limiting Congestion avoidance

MAC адреси:

16000 MAC address table size

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3ae, IEEE 802.3an, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q/p VLAN, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X

Описание

Комутатор Cisco SF550X-24P 24-port 10/100 PoE Stac

Виж повече caret
