Основни портове, тип:
24x10/100Base-TX
L2 мрежови стандарти:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.1ab (LLDP), IEEE 802.3az, IEEE 802.3z, IEEE 802.3x, IEEE 802.1D, IEEE 802.1Q/p VLAN, IEEE 802.1w, IEEE 802.1s, IEEE 802.1X
Памет (Flash, RAM):
Flash Memory: 256 MB RAM: 512 MB
VLAN (брой, стандарти):
Support for up to 4094 active VLANs simultaneously Port-based and 802.1Q tag-based VLANs MAC-based VLAN Management VLAN Private VLAN Guest VLAN Dynamic VLAN
Power Over Ethernet (PoE):
No
Пропускателна способност, Mpps:
63.09 Mpps
Stackable:
Hardware stack: Up to 8 units in a stack. Up to 400 ports managed as a single system with hardware failover.
Опция за монтаж:
Rack-mountable, 1RU
QoS:
Priority levels: 8 hardware queues Scheduling: Strict priority and weighted round-robin (WRR) Class of service Rate limiting Congestion avoidance
Управление:
Web user interface: Built-in switch configuration utility for easy browser-based device configuration (HTTP/HTTPS) SNMP: SNMP versions 1, 2c, and 3 with support for traps, and SNMP version 3 user-based security model (USM)
Сигурност:
SSH SSL IEEE 802.1X (authenticator role) Web-based authentication STP BPDU/Root Guard DHCP snooping Dynamic ARP Inspection (DAI) IP/MAC/Port Binding (IPMB) Secure Core Technology (SCT) Secure Sensitive Data (SSD) DoS prevention RADIUS/TACA
Захранване:
Internal power supply: 100-240V, 47-63 Hz Cisco external redundant power supply (RPS2300)
L3 мрежови стандарти:
IPv4 routing: Wirespeed routing of IPv4 packets, Up to 7K routes and up to 256 IP interfaces Wirespeed IPv6 static routing: Up to 7K routes and up to 256 IPv6 interfaces Routing Information Protocol version 2 for dynamic routing VRRP versions 2 an
IPv6 functionality:
IPv6 host mode IPv6 over Ethernet Dual IPv6/IPv4 stack IPv6 neighbor and router discovery (ND) IPv6 Stateless Address Autoconfiguration Path MTU Discovery IPv6 over IPv4 network with ISATAP tunnel support USGv6 and IPv6 Gold Logo certified
Uplink портове:
2 dual personality, 2x10GE SFP
Свободни (10GB) слотове:
No
MAC адреси:
16000 MAC address table size
Капацитет за маршрутизиране/превключване, Gbps:
84.8 Gbps
Fans:
1 + 1 (redundant) fans
