Power Over Ethernet (PoE):
Available PoE+ Power: 740 W
Сигурност:
Integrated multi-factor authentication for Dashboard management Role-based access control (RBAC) with granular device and configuration control IEEE 802.1X RADIUS and MAB, hybrid authentication and RADIUS server testing IPv4 and IPv6 ACLs
Fans:
Variable speed fans
VLAN (брой, стандарти):
802.1Q VLAN and trunking support for up to 4094 VLANs
Захранване:
Hot-swappable Power Supply Configuration Supported Power Supply: MA-PWR-1025WAC
QoS:
802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)
MAC адреси:
32000 MAC address table size
L3 мрежови стандарти:
Static routing, OSFPv2 (with support for up to 16 ECMP Routes), Multicast routing, Warm Spare (VRRP) - OSPF and Warm Spare do not operate concurrently, DHCP Server, DHCP Relay
Routing:
Layer 3 Advanced
Опция за монтаж:
Rackmount
Управление:
Managed via the Web with the Meraki cloud management platform Integrated with Meraki Wireless and complete portfolio of IT products and solutions SNMP and SYSLOG support for integration with other network management solutions
Размери (Ш, Д, В), mm:
485 x 517 x 44
Пропускателна способност, Mpps:
405 Mpps
Капацитет за маршрутизиране/превключване, Gbps:
544 Gbps
Свободни (10GB) слотове:
No
Основни портове, тип:
32x10/100/1000Base-T + 16x100M/1G/2.5G/5G/10G
Stackable:
2 x 100G QSFP28 stacking ports Physically stack up to 8 switches with 400 Gbps of stacking bandwidth Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration
Uplink портове:
2x40GE SFP or 4x10GE SFP
L2 мрежови стандарти:
IEEE 802.3, IEEE 802.3u, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab
