Fans:
Variable speed fans
Свободни (10GB) слотове:
No
Опция за монтаж:
Desktop/Rackmount
MAC адреси:
32000 MAC address table size
L2 мрежови стандарти:
IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab
Управление:
Managed via the Web with the Meraki cloud management platform Integrated with Meraki Wireless and complete portfolio of IT products and solutions SNMP and SYSLOG support for integration with other network management solutions
Routing:
Layer 3 Advanced
QoS:
802.1p Quality of Service, 8 queues (w/ 6 configurable for DSCP-to-CoS mapping)
Захранване:
Hot-swappable Power Supply Configuration Supported Power Supply: 2 x 250W PSU (Single power supply (PSU) included. For redundancy, second PSU is sold separately)
Сигурност:
Integrated multi-factor authentication for Dashboard management Role-based access control (RBAC) with granular device and configuration control IEEE 802.1X RADIUS and MAB, hybrid authentication and RADIUS server testing IPv4 and IPv6 ACLs
Uplink портове:
4x10GE SFP
L3 мрежови стандарти:
Static routing, OSFPv2, Warm Spare (VRRP) - OSPF and Warm Spare do not operate concurrently, DHCP Relay, DHCP Server
Power Over Ethernet (PoE):
No
Основни портове, тип:
48x10/100/1000Base-T
VLAN (брой, стандарти):
802.1Q VLAN and trunking support for up to 4094 VLANs
Stackable:
2 x stacking ports Physically stack up to 8 switches with 80 Gbps of stacking bandwidth Virtual Stacking supports thousands of switch ports in a single logical stack for unified management, monitoring, and configuration
Пропускателна способност, Mpps:
127.98 Mpps
Размери (Ш, Д, В), mm:
485 x 478 x 44
Капацитет за маршрутизиране/превключване, Gbps:
176 Gbps
