Комутатор Cisco Catalyst 9200L 48-port PoE+ 4x10G ... Виж още

Каталожен № на продукта: CISCO-C9200L-48P-4X-A
komutator-cisco-catalyst-9200l-48-port-poe-4x10g-cisco-c9200l-48p-4x-a
komutator-cisco-catalyst-9200l-48-port-poe-4x10g-cisco-c9200l-48p-4x-a
0 ревюта | 0 въпроса

  • Stackable Cisco StackWise-80 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200L-STACK-KIT=), Supported stack members: Other C9200L models with same license level (8 Number of members)
  • Капацитет за маршрутизиране/превключване, Gbps 176 Gbps
  • VLAN (брой, стандарти) VLAN IDs: 1024 IEEE 802.1Q VLAN
  • Общ брой портове 52
  • Power Over Ethernet (PoE) IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE Available PoE Power: 740W* (Default primary power supply - PWR-C5-1KWAC), 1440W* (Optional secondary power supply - PWR-C5-1KWAC), *Limited by port number and port rating

7508.80 €
14685.94 лв.
Неналичен. Цената може да бъде различна, когато отново има наличност.
Добави в Любими
Поръчка по телефон Без формалности
komutator-cisco-catalyst-9200l-48-port-poe-4x10g-cisco-c9200l-48p-4x-a
Комутатор Cisco Catalyst 9200L 48-port PoE+ 4x10G uplink Switch, Network Advantage
7508.80 € 14685.94 лв.
Характеристики Описание Ревюта Въпроси и отговори
Характеристики
Захранване:
Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-1KWAC
IPv6 functionality:
IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
Fans:
Fixed redundant
Stackable:
Cisco StackWise-80 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200L-STACK-KIT=), Supported stack members: Other C9200L models with same license level (8 Number of members)
Капацитет за маршрутизиране/превключване, Gbps:
176 Gbps
Пропускателна способност, Mpps:
261.9 Mpps
VLAN (брой, стандарти):
VLAN IDs: 1024 IEEE 802.1Q VLAN
Общ брой портове:
52
MAC адреси:
16000 MAC address
Power Over Ethernet (PoE):
IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE Available PoE Power: 740W* (Default primary power supply - PWR-C5-1KWAC), 1440W* (Optional secondary power supply - PWR-C5-1KWAC), *Limited by port number and port rating
Други:
Задължителен е минимум 3-годишен лиценз DNA Advantage.
Uplink портове:
4x10GBase-T
Сигурност:
Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
L3 мрежови стандарти:
Advanced IP unicast routing protocols: full OSFP, EIGRP, IS-ISv4
Опция за монтаж:
Rackmount
Размери (Ш, Д, В), mm:
445 x 288 x 44
Памет (Flash, RAM):
Flash memory: 4 GB RAM: 2 GB DRAM
Основни портове, тип:
48x10/100/1000Base-T
Routing:
Layer 3 Advanced
Гаранция:
99 месеца
QoS:
Granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per
Управление:
SNMPv1, SNMPv2c, and SNMPv3 RMON I and II standards Internet Group Management Protocol (IGMP) CLI TCP UDP
Свободни (10GB) слотове:
No
L2 мрежови стандарти:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
Суич, тип:
Fixed Port
Описание

Комутатор Cisco Catalyst 9200L 48-port PoE+ 4x10G
