Комутатор Cisco Catalyst 9200L 24-port PoE+ 4x1G u ... plink Switch, Network Advantage Виж още

Name: Комутатор Cisco Catalyst 9200L 24-port PoE+ 4x1G uplink Switch, Network Advantage
Brand: CISCO
SKU: CISCO-C9200L-24P-4G-A
Price: 5541.30000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Каталожен № на продукта: CISCO-C9200L-24P-4G-A

komutator-cisco-catalyst-9200l-24-port-poe-4x1g-u-cisco-c9200l-24p-4g-a

0 ревюта | 0 въпроса

Памет (Flash, RAM) Flash memory: 4 GB RAM: 2 GB DRAM
Основни портове, тип 24x10/100/1000Base-T
Капацитет за маршрутизиране/превключване, Gbps 56 Gbps
MAC адреси 16000 MAC address
L2 мрежови стандарти IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x

Сравни

5541.30 лв.

2833.22 €

Неналичен. Цената може да бъде различна, когато отново има наличност.

Добави в Любими

Купи с :

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

Размери (Ш, Д, В), mm:

445 x 288 x 44

Опция за монтаж:

Rackmount

Суич, тип:

Fixed Port

Други:

Задължителен е минимум 3-годишен лиценз DNA Advantage.

Fans:

Fixed redundant

Uplink портове:

4x10/100/1000Base-T

Гаранция:

99 месеца

Памет (Flash, RAM):

Flash memory: 4 GB RAM: 2 GB DRAM

L3 мрежови стандарти:

Advanced IP unicast routing protocols: full OSFP, EIGRP, IS-ISv4

Основни портове, тип:

24x10/100/1000Base-T

QoS:

Granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per

Капацитет за маршрутизиране/превключване, Gbps:

56 Gbps

Пропускателна способност, Mpps:

83.33 Mpps

MAC адреси:

16000 MAC address

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x

Stackable:

Cisco StackWise-80 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200L-STACK-KIT=), Supported stack members: Other C9200L models with same license level (8 Number of members)

Power Over Ethernet (PoE):

IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE Available PoE Power: 370W* (Default primary power supply - PWR-C5-600WAC), 740W* (Optional secondary power supply - PWR-C5-600WAC), *Limited by port number and port rating

Сигурност:

Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems

Захранване:

Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-600WAC

Управление:

SNMPv1, SNMPv2c, and SNMPv3 RMON I and II standards Internet Group Management Protocol (IGMP) CLI TCP UDP

VLAN (брой, стандарти):

VLAN IDs: 1024 IEEE 802.1Q VLAN

Свободни (10GB) слотове:

Routing:

Layer 3 Advanced

IPv6 functionality:

IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting

Общ брой портове:

Описание

Комутатор Cisco Catalyst 9200L 24-port PoE+ 4x1G u
