Name: Комутатор Cisco Catalyst 9200L 24-port Data 4x1G uplink Switch, Network Advantage
Brand: CISCO
SKU: CISCO-C9200L-24T-4G-A
Price: 3845.60000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

QoS:

Granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per

MAC адреси:

16000 MAC address

Размери (Ш, Д, В), mm:

445 x 288 x 44

Routing:

Layer 3 Advanced

Суич, тип:

Fixed Port

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x

Fans:

Fixed redundant

VLAN (брой, стандарти):

VLAN IDs: 1024 IEEE 802.1Q VLAN

Захранване:

Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-125WAC

Капацитет за маршрутизиране/превключване, Gbps:

56 Gbps

Общ брой портове:

Uplink портове:

4x10/100/1000Base-T

L3 мрежови стандарти:

Advanced IP unicast routing protocols: full OSFP, EIGRP, IS-ISv4

Гаранция:

99 месеца

Управление:

SNMPv1, SNMPv2c, and SNMPv3 RMON I and II standards Internet Group Management Protocol (IGMP) CLI TCP UDP

Свободни (10GB) слотове:

Други:

Задължителен е минимум 3-годишен лиценз DNA Advantage.

Power Over Ethernet (PoE):

Сигурност:

Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems

Опция за монтаж:

Rackmount

Основни портове, тип:

24x10/100/1000Base-T

Памет (Flash, RAM):

Flash memory: 4 GB RAM: 2 GB DRAM

IPv6 functionality:

IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting

Пропускателна способност, Mpps:

83.33 Mpps

Stackable:

Cisco StackWise-80 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200L-STACK-KIT=), Supported stack members: Other C9200L models with same license level (8 Number of members)

Описание

Комутатор Cisco Catalyst 9200L 24-port Data 4x1G u

Виж повече caret
