Name: Комутатор Cisco Catalyst 9200 24-port PoE+ Switch, Network Advantage
Brand: CISCO
SKU: CISCO-C9200-24P-A
Price: 5751.20000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

VLAN (брой, стандарти):

VLAN IDs: 4096 IEEE 802.1Q VLAN

L3 мрежови стандарти:

Advanced IP unicast routing protocols: full OSFP, EIGRP, IS-ISv4

Routing:

Layer 3 Advanced

Пропускателна способност, Mpps:

190.4 Mpps

Основни портове, тип:

24x10/100/1000Base-T

Капацитет за маршрутизиране/превключване, Gbps:

128 Gbps

Управление:

SNMPv1, SNMPv2c, and SNMPv3 RMON I and II standards Internet Group Management Protocol (IGMP) CLI TCP UDP

Размери (Ш, Д, В), mm:

445 x 350 x 44

Uplink портове:

Power Over Ethernet (PoE):

IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE Available PoE Power: 370W* (Default primary power supply - PWR-C5-600WAC), 740W* (Optional secondary power supply - PWR-C5-600WAC), *Limited by port number and port rating

MAC адреси:

32000 MAC address

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x

Stackable:

Cisco StackWise-160 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200-STACK-KIT=), Supported stack members: Other C9200 models with same license level (8 Number of members)

Други:

Задължителен е минимум 3-годишен лиценз DNA Advantage.

Fans:

Field-Replaceable Units (FRU) redundant

Гаранция:

99 месеца

Общ брой портове:

Сигурност:

Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems

QoS:

Granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per

Опция за монтаж:

Rackmount

Свободни (10GB) слотове:

Modular uplink options (C9200-NM-4G, C9200-NM-4X)

Суич, тип:

Fixed Port

Захранване:

Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-600WAC

IPv6 functionality:

IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting

Памет (Flash, RAM):

Flash memory: 4 GB RAM: 4 GB DRAM

Описание

Комутатор Cisco Catalyst 9200 24-port PoE+ Switch,
