Комутатор Cisco Catalyst 9200 24-port PoE+ Switch, ... Виж още

Каталожен № на продукта: CISCO-C9200-24P-A
komutator-cisco-catalyst-9200-24-port-poe-switch-cisco-c9200-24p-a
komutator-cisco-catalyst-9200-24-port-poe-switch-cisco-c9200-24p-a
0 ревюта | 0 въпроса

  • Uplink портове 0
  • MAC адреси 32000 MAC address
  • Сигурност Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
  • L3 мрежови стандарти Advanced IP unicast routing protocols: full OSFP, EIGRP, IS-ISv4
  • Основни портове, тип 24x10/100/1000Base-T

2940.50 €
5751.12 лв.
Неналичен. Цената може да бъде различна, когато отново има наличност.
Добави в Любими
Поръчка по телефон Без формалности
komutator-cisco-catalyst-9200-24-port-poe-switch-cisco-c9200-24p-a
Комутатор Cisco Catalyst 9200 24-port PoE+ Switch, Network Advantage
2940.50 € 5751.12 лв.
Характеристики Описание Ревюта Въпроси и отговори
Характеристики
Power Over Ethernet (PoE):
IEEE 802.3at PoE+ (up to 30W per port), Perpetual PoE, Fast PoE Available PoE Power: 370W* (Default primary power supply - PWR-C5-600WAC), 740W* (Optional secondary power supply - PWR-C5-600WAC), *Limited by port number and port rating
Uplink портове:
0
Stackable:
Cisco StackWise-160 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200-STACK-KIT=), Supported stack members: Other C9200 models with same license level (8 Number of members)
MAC адреси:
32000 MAC address
L2 мрежови стандарти:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x
Управление:
SNMPv1, SNMPv2c, and SNMPv3 RMON I and II standards Internet Group Management Protocol (IGMP) CLI TCP UDP
Сигурност:
Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems
QoS:
Granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per
Памет (Flash, RAM):
Flash memory: 4 GB RAM: 4 GB DRAM
Други:
Задължителен е минимум 3-годишен лиценз DNA Advantage.
Общ брой портове:
24
IPv6 functionality:
IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting
Fans:
Field-Replaceable Units (FRU) redundant
VLAN (брой, стандарти):
VLAN IDs: 4096 IEEE 802.1Q VLAN
L3 мрежови стандарти:
Advanced IP unicast routing protocols: full OSFP, EIGRP, IS-ISv4
Routing:
Layer 3 Advanced
Захранване:
Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-600WAC
Капацитет за маршрутизиране/превключване, Gbps:
128 Gbps
Опция за монтаж:
Rackmount
Свободни (10GB) слотове:
Modular uplink options (C9200-NM-4G, C9200-NM-4X)
Размери (Ш, Д, В), mm:
445 x 350 x 44
Гаранция:
99 месеца
Пропускателна способност, Mpps:
190.4 Mpps
Основни портове, тип:
24x10/100/1000Base-T
Суич, тип:
Fixed Port
Описание

Комутатор Cisco Catalyst 9200 24-port PoE+ Switch,
