Name: Комутатор Cisco Catalyst 9200 24-port Data Switch, Network Essentials
Brand: CISCO
SKU: CISCO-C9200-24T-E
Price: 2561.90000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

Основни портове, тип:

24x10/100/1000Base-T

Суич, тип:

Fixed Port

Размери (Ш, Д, В), mm:

445 x 350 x 44

Промоция:

Специална цена. Валидност до 23.01.2026г.

Захранване:

Dual field-replaceable power supplies, Default primary AC power supply: PWR-C5-125WAC

MAC адреси:

32000 MAC address

Routing:

Layer 3 Advanced

Памет (Flash, RAM):

Flash memory: 4 GB RAM: 4 GB DRAM

VLAN (брой, стандарти):

VLAN IDs: 4096 IEEE 802.1Q VLAN

Свободни (10GB) слотове:

Modular uplink options (C9200-NM-4G, C9200-NM-4X)

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3bz, IEEE 802.3ad, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.1x-Rev, IEEE 802.3x

Fans:

Field-Replaceable Units (FRU) redundant

Power Over Ethernet (PoE):

Капацитет за маршрутизиране/превключване, Gbps:

128 Gbps

Гаранция:

99 месеца

Stackable:

Cisco StackWise-160 stacking ports: copper-based Cisco StackWise cabling, Stacking hardware (C9200-STACK-KIT=), Supported stack members: Other C9200 models with same license level (8 Number of members)

IPv6 functionality:

IPv6 routing (using OSPFv3 and EIGRPv6) is supported in hardware for maximum performance IPv6 addressing is supported on interfaces with appropriate show commands for monitoring and troubleshooting

Други:

Задължителен е минимум 3-годишен лиценз DNA Essentials.

L3 мрежови стандарти:

IP unicast routing protocols: Static, Routing Information Protocol Version 1 [RIPv1], and RIPv2, RIPng, Open Shortest Path First [OSPF]

Общ брой портове:

Сигурност:

Enhanced security with AES-128 MACsec encryption, policy-based segmentation, and trustworthy systems

Пропускателна способност, Mpps:

190.4 Mpps

Опция за монтаж:

Rackmount

Uplink портове:

QoS:

Granular wireless bandwidth management and fair sharing, 802.1p Class of Service (CoS) and Differentiated Services Code Point (DSCP) field classification, Shaped Round Robin (SRR) scheduling, Committed Information Rate (CIR), and eight egress queues per

Управление:

SNMPv1, SNMPv2c, and SNMPv3 RMON I and II standards Internet Group Management Protocol (IGMP) CLI TCP UDP

Описание

Комутатор Cisco Catalyst 9200 24-port Data Switch,
