Uplink портове:
4x 10G SFP+
L2 мрежови стандарти:
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3az, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.1ax, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.3x, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.
Свободни (10GB) слотове:
No
Размери (Ш, Д, В), mm:
445 x 240 x 44
Power Over Ethernet (PoE):
No
Опция за монтаж:
Desktop/Rackmount
Памет (Flash, RAM):
Flash memory: 256 MB RAM: 512 MB DRAM
VLAN (брой, стандарти):
Maximum active VLANs: 256 VLAN IDs available: 4094 IEEE 802.1Q VLAN
Основни портове, тип:
24x10/100/1000Base-T
Сигурност:
Comprehensive 802.1X 802.1x support with NEAT Disable per-VLAN MAC learning Multidomain/AAA command authorization ACLS Port-based ACLs SSH, Kerberos, and SNMPv3 SPAN TACACS+/ RADIUS/MAC authentication MAC address/Web notification BPDU and e
Пропускателна способност, Mpps:
41.67 Mpps
Капацитет за маршрутизиране/превключване, Gbps:
128 Gbps
Други:
1 x RJ45 Ethernet, 1 x USB mini-B, 1 x USB-A port for storage and Bluetooth console
Захранване:
Single fixed power supply, 110 to 220V AC
QoS:
Up to eight egress queues and two thresholds per port Ingress policing DSCP Traffic Classification Trust Boundary Auto-QoS Shaped Round Robin (SRR) scheduling and Weighted Tail Drop (WTD) 802.1p Class of Service (CoS)
L3 мрежови стандарти:
RFC 1256 - Internet Control Message Protocol (ICMP) Router Discovery, RFC 792 - ICMP, RFC 791 - IP, RFC 793 - TCP, RFC 768 - UDP
MAC адреси:
16000 MAC address table size
Управление:
SNMP, web UI, Bluetooth for over-the-air access, Virtual Stacking, DHCP, Internet Group Management Protocol (IGMP), Trivial File Transfer Protocol (TFTP), RMON, TCP
IPv6 functionality:
IPv6 unicast direct routes: 414 IPv6 unicast indirect routes: 128 IPv6 static routes: 16 IPv6 multicast groups: 1024 IPv6 security ACEs: 256
