Name: Комутатор Cisco Catalyst 2960L 24 port GigE, 4 x 1G SFP, LAN Lite
Brand: CISCO
SKU: CISCO-WS-C2960L-24TS-LL
Price: 2982.70000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

Основни портове, тип:

24x10/100/1000Base-T

Общ брой портове:

Routing:

Layer 2 Only

Uplink портове:

4xSFP

Размери (Ш, Д, В), mm:

445 x 240 x 44

Свободни (10GB) слотове:

Stackable:

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3az, IEEE 802.3ae, IEEE 802.1ax, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1X, IEEE 802.3x, IEEE 802.1ab, IEEE 802.3ad, IEEE 802.3ah

Гаранция:

99 месеца

QoS:

Up to four egress queues and two thresholds per port supporting bandwidth control, shaping, and priority queuing so that the high priority packets are serviced ahead of other traffic WRR scheduling and WTD congestion avoidance 802.1p class of servi

L3 мрежови стандарти:

Капацитет за маршрутизиране/превключване, Gbps:

56 Gbps

IPv6 functionality:

IPv6 Ready Logo

Суич, тип:

Fixed Port

Fans:

Fanless design

VLAN (брой, стандарти):

Maximum active VLANs: 64 VLAN IDs available: 4094 IEEE 802.1Q VLAN

Захранване:

Single fixed power supply, 110 to 220V AC

Управление:

CLI for detailed configuration and administration, DHCP, Internet Group Management Protocol (IGMP), Trivial File Transfer Protocol (TFTP), SNMP v1, v2c, and v3, RMON, TCP, UDP

Power Over Ethernet (PoE):

Опция за монтаж:

Desktop/Rackmount

Сигурност:

Comprehensive 802.1x, Multidomain Authentication, Access Control Lists (ACLs), SSH, Kerberos, SNMPv3, Switched Port Analyzer (SPAN), TACACS+ and RADIUS authentication, MAC address notification, Multilevel security on console access, BPDU guard, STRG

MAC адреси:

8000 MAC address table size

Памет (Flash, RAM):

Flash memory: 256 MB RAM: 512 MB DRAM

Пропускателна способност, Mpps:

41.67 Mpps

Други:

1 x RJ45 Ethernet, 1 x USB mini-B, 1 x USB-A port for storage and Bluetooth console

Описание

Комутатор Cisco Catalyst 2960L 24 port GigE, 4 x 1
