Name: Комутатор Aruba 2530 8 Switch
Brand: HPE
SKU: HPE-J9783A
Price: 564.30000000000000000000 BGN
Availability: InStock
Rating: 0 (0 reviews)

Характеристики Описание Ревюта Въпроси и отговори

Характеристики

Размери (Ш, Д, В), mm:

254 x 160 x 45

Суич, тип:

Fixed Port

Други:

1 dual-personality (RJ-45 or USB micro-B) serial console port

Захранване:

External power adapter Input voltage: 100-127/200-240 VAC Maximum power rating: 7.2 W

Fans:

Fanless design

MAC адреси:

16000 MAC addres table size

Основни портове, тип:

8x10/100Base-TX

Power Over Ethernet (PoE):

QoS:

Traffic prioritization (IEEE 802.1p) Simplified QoS configuration: Port-based, VLAN-based Class of Service (CoS) Rate limiting Layer 4 prioritization Flow control

Опция за монтаж:

Rackmount

Капацитет за маршрутизиране/превключване, Gbps:

5.6 Gbps

L2 мрежови стандарти:

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q VLANs, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x Flow Control

Свободни (10GB) слотове:

Пропускателна способност, Mpps:

4.1 Mpps

VLAN (брой, стандарти):

VLANs: provide support for 512 VLANs and 4, 094 VLAN IDs GARP VLAN Registration Protocol: allows automatic learning and dynamic assignment of VLANs IEEE 802.1Q VLANs

Stackable:

Virtual stacking: single IP address management of up to 16 switches

Гаранция:

99 месеца

Памет (Flash, RAM):

Flash Memory: 128 MB, RAM: 256 MB DDR3 DIMM

Routing:

Layer 2 Only

L3 мрежови стандарти:

Общ брой портове:

Управление:

Web graphical user interface (GUI), Command-line (CLI), Simple Network Management Protocol (SNMPv1/v2c/v3), sFlow, IEEE 802.1AB Link Layer Discovery Protocol (LLDP), Port mirroring, RMON (remote monitoring), Friendly port names, Dual flash images

Uplink портове:

2 dual personality

IPv6 functionality:

IPv6 host Dual stack (IPv4/IPv6) MLD snooping

Сигурност:

Access control lists (ACLs) RADIUS/TACACS+ Source-port filtering SSL Port security IEEE 802.1X Web/MAC-based authentication Secure shell (SSHv2 client and server) STP BPDU port protection STP Root Guard Secure FTP Protected ports CLI

Описание

Комутатор Aruba 2530 8 Switch
