Форм-фактор:
Full height half length
Host интерфейс:
PCIe 3.0 x8
Максимална мрежова скорост, Gbit/s:
12 Gb/s
Други:
Controller chip: LSI SAS3508 + LSI SAS35x36R RAID levels: 0, 1, 10, 5, 50, 6, 60, JBOD Cache: 4GB (Standard) CacheVault cache protection with flash, Performance Accelerator (FastPath), SED support (SafeStore)
Интерфейс:
Port interface: 12 Gb SAS, Number of ports: 24 Port connectors: 6x Mini-SAS HD x4 (SFF-8643) Drive interface: SAS, SATA Drive type: HDD, SSD, SED
Мрежови стандарти:
FCC Part 15 Class A, Europe (EN55022/EN55024), RoHS compliant, EN/IEC/UL 60950, WEEE
